What You Need to Know About Differences in Wind-Speed Reporting for Hurricanes

This week’s post was written by Darren Conrad, PE. Engineering Manager, Truss at Simpson Strong-Tie.

With Hurricane Irma wrapping up, the cleanup after Hurricane Harvey’s devastation underway in Houston and more big storms already churning in the Atlantic, it seems like a good time to discuss hurricanes and high wind. There is a great deal of good information out there to help us better understand hurricanes and their impact on people, structures and other property. To improve awareness of wind speeds and their measurement, this article will discuss a commonly misunderstood aspect of hurricane wind-speed reporting.

When a storm is approaching, you will hear meteorologists report wind speeds. They often refer to storm categories. These categories attempt to generalize expected damage to structures based on the wind speed of the storm. The wind speed for a given storm is a measure of the severity of the storm and the danger it poses to life and property. But how do meteorologists determine the wind speed that they are reporting? It seems so concrete and certain, but anyone who has been outside during a storm or windy day knows that wind isn’t constant at any one location over a period of time. It varies continuously in magnitude and direction over time. So how can something so variable be the subject of knowledge that is precise enough to be useful? How do we understand wind-speed measurements and make sure that when comparing them we are doing so in such a way that they are comparable? That is a great question.

The good news is that even though wind is variable, we have a commonly accepted way to measure wind speed and know something about a wind field or event that is occurring at a time and place. This is done by averaging measured wind speeds over specified lengths of time, or picking the highest average wind speed that occurs for a specified averaging interval from a longer period of time. A great resource for understanding how wind speeds are measured and reported can be seen here. From this explanation, it can be seen that a reported wind speed is meaningless without a specified averaging time. The shortest averaging intervals will yield the highest reported wind speeds. The longer averaging times will capture more peaks and lulls and yield lower reported wind speeds. The most common averaging intervals used to report wind speeds are three seconds, one minute and two minutes. Some countries even use a ten-minute averaging interval for reporting wind speeds. So the question arises, which average is correct? And the answer is, none of them and all of them. They are just different ways of looking at measured wind data. That is not very comforting, but one thing we can know is that none of them can be truly interpreted or compared without understanding this idea of averaging time. To make it more confusing, meteorologists and building codes do not use the same averaging interval when reporting or specifying wind speeds. This can lead to misunderstandings.

In general, you will hear meteorologists report sustained wind speeds when covering an approaching hurricane. They might also mix in some peak gusts, but for the most part they focus on sustained wind speeds. Sustained wind speeds for tropical cyclones use a 60-second averaging time. Sustained wind speed is also used by the Saffir-Simpson scale to roughly quantify the likely damage that the wind from a storm might cause typical buildings and other structures. There are criticisms of the accuracy of the Saffir-Simpson scale method, but it is widely used by the public to generalize about the severity of tropical cyclones; therefore, it is likely that the public might and commonly does attempt to compare reported sustained wind speeds to building-code-specified three-second-gust wind speeds to determine if their house or structure will withstand the storm. There is danger in making that comparison.

We need to be careful when comparing the reported sustained wind speed for a storm with the three-second-gust design wind speeds referenced in building codes and design standards. They are not the same and need to be converted before they can be compared for equivalence. After seeing the following example, one could easily see the possibility of the public or a public official comparing the sustained wind speeds reported by the weatherman to the wind speeds used by building codes and design standards and drawing conclusions that may underestimate the force and effect of the storm.

Let’s take a hypothetical situation where a building jurisdiction has adopted a wind speed of 130 mph three-second-gust design wind speed for structures built in that jurisdiction. There are various methods to convert wind speeds between different averaging times, and many factors that may need to be considered when doing that. One method for converting is the Durst method referenced in ASCE 7. Another more recent method recommended by the World Meteorological Organization provides a pretty straightforward conversion between sustained wind speed and three-second-gust wind speeds for near-surface applications. So for the sake of simplicity, we will use it for this example. If we convert a reported sustained wind speed of 130 mph to a three-second-gust average wind speed using this method, it equates to a three-second-gust wind speed for Off-Sea of 160 mph (Off-Sea is appropriate for an approaching hurricane). The adopted130 mph three-second-gust wind speed converts to 105 mph sustained wind speed. This difference could lead individuals in the path of the storm to underestimate its severity if they are not aware of the difference between averaging intervals for wind speeds. They could see the sustained wind speed of 130 mph being reported by the weather service when the storm is over open water and assume that their structure, or structures in their jurisdiction, will stand up fairly well. This would be a serious underestimate, since those structures would need to be designed to resist a 160 mph three-second-gust wind speed using ASCE 7 in order for that to be true. To say that a different way, one might think that their structure was designed for a Category 4 storm (130 mph sustained), when in fact it was actually designed for a Category 2 storm (105 mph sustained) using the Saffir-Simpson scale. Hurricane Irma at its maximum sustained wind speed of 185 mph would equate to a 227 mph three-second-gust wind speed using this conversion method. From a roof anchorage, lateral design and load path design perspective, the difference between 130 mph and 160 mph can be substantial, especially when the building is located on flat open terrain where Exposure C or Exposure D are appropriate assumptions for the design.

There is a lot more background and detail to this very complicated discussion, but the general point is to know your averaging times when comparing reported wind speeds, so as not to underestimate a storm’s force. If a storm is headed your way, hopefully you have already selected the proper hurricane tie for your structure; you have a well-defined and properly designed continuous load path; and you are protecting your exterior openings from windborne debris. Remember, the objective is not to protect the window or door product itself. Unless you are in the insurance business, you are preventing the breach of the opening to keep wind from pressurizing the structure, increasing loads on the structure and potentially causing catastrophic failure.

Know how to secure your structure against high winds, and be safe.

Code Update: Revisions Finalized for the 2018 IRC

This blog post continues our series on the final results of the 2016 ICC Group B Code Change Hearings. This post will focus on approved changes to the International Residential Code (IRC) that are of a structural nature. The changes outlined here will be contained in the 2018 IRC, which is expected to be published in the fall of this year.

In Chapter 3, the seismic design category / short-period design spectral response acceleration maps will be updated to match the new USGS/NEHRP Seismic Maps. These new maps are based on the worst case assumption for Site Class. Significantly, a new set of maps will be provided in Figure 301.2(3) “Alternate Seismic Design Categories”. These are permitted to be used when the “soil conditions are determined by the building official to be Site Class A, B or D.” See page 29 of the linked document for the new maps and a good explanation of the changes that will be occurring in various parts of the country. In addition, the ICC Building Code Action Committee authored a reorganization of the seismic provisions of Chapter 3 to try to reduce confusion.

Another change in Chapter 3 will clarify that guards are only required on those portions of walking surfaces that are located more than 30 inches above grade, not along the entire surface. To bring consistency with the IBC, another change will require that staples in treated wood be made of stainless steel.

A broad group of parties interested in deck safety, known as the Deck Code Coalition, submitted 17 different code changes with revisions to Section R507 on decks. Of those, 12 were approved, making significant changes to that section. The various approved changes included the following: a complete re-write of that section; new/clarified requirements for deck materials, including wood, fasteners and connectors; clarified requirements for vertical and lateral connections of the deck to the supporting structure; new requirements for sizes of deck footings and specification that deck footings must extend below the frost line, with certain exceptions; clarification for deck board material, including an allowance for alternative decking materials and fastening methods; adding new columns to the deck joist span table that show the maximum cantilever for joists; adding the allowance for 8×8 deck posts, to allow notching for the support of a three-ply beam; and clarification of the deck-post-to-footing connection.

In Chapter 6, a new table permitting 11ʹ- and 12ʹ- long studs was added. In the 2015 IRC, load-bearing studs were limited to 10 feet in length. A new high-capacity nail, the RSRS (Roof Sheathing Ring Shank) nail was added as an option for fastening roof sheathing. This nail will become more widely used once the higher roof component and cladding forces from ASCE 7-16 are adopted. The rim board header detail that was added for the 2015 IRC was corrected to show that hangers are required in all cases when the joists occur over the wall opening.

There were several changes made to the Wall Bracing Section, R602.10. The use of the 2.0 increase factor was clarified for use when the horizontal joints in braced wall panel sheathing are not blocked. Narrow methods were added to the column headings for the wind and seismic bracing amount tables, to make them consistent, and the methods for adding different bracing were clarified. When using bracing method PFH, the builder can omit the nailing of the sheathing to the framing behind the strap-type holdown. Finally, offering some relief for high-seismic areas where brick veneer is used, an allowance was added to permit a limited amount of brick veneer to be present on the second floor without triggering the use of the BV-WSP bracing method.

In Chapter 8, the requirements for a “stick-framed” roof system were completely re-written to make such systems easier to use.

A couple of significant changes were made to the prescriptive requirements for cold-formed steel framing. The requirements for the anchorage of cold-formed steel walls were revised, and the wind requirements for cold-formed steel framing were changed to match the new AISI S230 prescriptive standard.

Finally, it may be helpful to mention some of the proposed changes that were not adopted. While the new ASCE 7-16 was adopted as the IRC reference standard for loads as part of the Administrative changes, several changes to the IRC to make it consistent with ASCE 7-16 were not approved. A change to update the IRC wind speed maps, roof component and cladding pressures, component and cladding roof zones, and revise the remainder of wind-based requirements to match ASCE 7-16 was not approved. Similarly, a proposal to increase the live load on decks, from 1.0 to 1.5 times the occupancy served, was denied.

Once the IRC is published, it will be time to start a new code change cycle once again, with Group A code changes due January 8, 2018. The schedule for the next cycle is already posted here.

What changes would you like to see for the 2021 codes?

Building Code Update: 2018 IBC to Reference ASCE 7-16

In early December, ICC posted the preliminary results of the Group B Online Governmental Consensus Vote, which included structural changes to the IBC, IEBC and IRC. ICC reports that there were more than 162,000 votes cast by eligible Voting Members during the three-week online voting period.

One subject of interest to building Designers, builders and some building-material suppliers was the disposition of a group of code changes that adopted ASCE 7-16 as the reference standard on loads for the IBC and IRC, and changed other parts of the IBC and IRC to reflect that.

The most controversial part of adopting the new ASCE 7-16 standard was its increase in roof component and cladding loads. The higher pressure coefficients in some cases raised the concern that the cost of roofing, roofing materials and roof repairs would be increased. Other items that raised some opposition were the new chapter on tsunami loads and the increase in deck and balcony live loads from 40 psf to 60 psf.

Despite these concerns, ICC members voted to approve the code change that adopted ASCE 7-16 as the reference for loads in the 2018 IBC, IRC and IEBC.

Along with that specific change, several other related changes were approved to correlate the IBC with adoption of ASCE 7-16. These included changes to Section 1604, General Design Requirements; adding in a new Section 1615 on Tsunami Design Requirements; modifications to Section 1613 so that seismic design requirements match ASCE 7-16; and deletion of Section 1609.6, Alternate All-Heights Method for wind design. On this last item, the argument was that since ASCE 7 now includes a simplified wind load design method, a competing method is not needed in the IBC.

Interestingly, a change to remove Strength Design and Allowable Stress Design load combinations from the IBC, which was approved by the IBC Structural Committee, was overturned and denied by the ICC Member voters. So those will remain in the IBC.

For the IRC, even though ASCE 7-16 will be shown as the referenced load standard, most changes to the actual code language relating to the new standard were denied. Items that were specifically denied included adoption of ASCE 7-16 wind speed maps, adoption of ASCE 7-16 roof pressure loading, and adoption of the new higher deck and balcony live loads. So the result is that the IBC and IRC will again be inconsistent with each other regarding wind design. On the other hand, the new USGS/NEHRP Seismic Design Maps were approved.

Future Code Corner articles will address other changes approved for the 2018 IBC and IRC.



Getting Involved and Staying Connected in the Industry

This week’s post is courtesy of Annie Tran Kao, Simpson Strong-Tie field engineer for the Southern California region. Prior to joining Simpson Strong-Tie in 2006 as a branch engineer, Annie worked as a project engineer for new and retrofit commercial and residential projects for a structural engineering consulting firm in Orange County, Calif. She also performed seismic evaluations of structures as an intern with a structural engineering firm in San Francisco. Annie is a licensed professional engineer in California and is registered with the National Council of Examiners for Engineering and Surveying. She received her Bachelor’s degree in Engineering from Harvey Mudd College and her Master’s degree in Structural Engineering from UC Berkeley. She is an active member of SEAOSC.

I’m excited to share some tips on getting more involved with the structural engineering community. There are many organizations and industry associations related to structural engineering that it can feel daunting to try to meet all of the key players and make a name for yourself.

I have a really unique and fun job at Simpson Strong-Tie as a field engineer for our light-frame construction products, which include connectors, fasteners, and lateral systems.  As a field engineer, I spend most of my time out on the road visiting engineers, architects, building officials, contractors, and others who need technical assistance using our product lines. While this means I spend a good chunk of time in SoCal traffic, I do get to talk to lots of different people working on projects ranging from small home remodels that might be using our new Strong-Frame® special moment frame to huge multi-family housing projects with several thousand units.

I also make sure to attend as many industry association functions as I can, because these are the best places to network and meet other professionals. There are many great organizations, including the Structural Engineers Association, which has chapters all over the United States. The California chapters have very strong participation. I also suggest getting involved in other industry organizations that include people outside of the profession, such as building officials, inspectors, contractors, builders, and architects. These people play an integral part in the construction industry and it’s important to understand their role and importance in supporting structural engineering.

Continue reading

What Did Sandy Teach Us?

Shane Vilasineekul

Guest blogger Shane Vilasineekul, engineering manager

This week’s blog post is authored by Shane Vilasineekul, who is the Simpson Strong-Tie Engineering Manager for our Columbus, Ohio branch covering the Northeastern United States. Shane is our latest blogger for the Structural Engineering Blog. He will be posting occasionally on topics that are relevant to our work. We will continue to post on a regular weekly schedule to the blog. In the future, we hope to expand the voices on the blog to include more Simpson Strong-Tie engineers, along with other industry colleagues and associates. For more information on Shane, see his bio here. Here is Shane’s post:

In the weeks following Hurricane Sandy, I had an opportunity to visit some of the hardest hit communities in the region. At the time, many of New Jersey’s barrier islands were still completely closed off to civilian traffic and all accessible bridges were blocked by military guards. Our local territory manager has great relationships with building departments, so we were able to walk portions of Long Beach Island, NJ with an inspector. The storm surge washed out several sections of the protective sand dunes on the south end of the island in the neighborhood of Holgate and this is where we spent much of the day.

Holgate, NJ

Holgate, NJ

Scoured foundation temporarily shored. Holgate, NJ.

Scoured foundation temporarily shored. Holgate, NJ.

For a structural engineer, there was a lot to observe and many things I could write about here (maybe a future post), but what strikes me the most when looking back is the long- term impact this event will have on the region. The cost of Sandy goes beyond the loss of life and property (72 lives, $50 billion and growing). It would be difficult to estimate a dollar amount that accounts for the displacement of people and disruption to their lives, the hit to local economies that depend heavily on tourism, and the effect on the national economy and taxpayers; but I imagine it would be a staggering sum. So what, if anything, can structural engineers do about it? Continue reading
